Why Is It Important To Use a Dedicated Calibration Facility?
Space Requirements For ADAS Calibration
To perform accurate ADAS calibrations, a shop requires a workspace that is generally 25-40 feet long and 15-30 feet wide, depending on the specific calibration needs and equipment used. Some calibrations, like forward-facing camera and radar, may only require 10-30 feet of space in front of the vehicle. Dynamic calibrations, which involve road testing, necessitate a suitable roadway with specific conditions. Here at Precision Calibration our dedicated calibration facility
bays are 30’ by 50’. This work space allows for various calibration needs and allows vehicle repositioning as necessary during the process.
Static ADAS Calibrations
The majority of vehicles start with static calibration. Static ADAS Calibration takes place in a controlled environment while the car is stationary. ADAS static Calibration uses special tools in a specially rendered environment to precisely set sensor angles. For proper static calibrations, technicians need::
- Minimum of a 30' x 50' space
- A level finished floor
- Uniform neutral color on walls and floor
- Uniform and adjustable lighting
- Unobstructed space around the vehicle
- No reflective surfaces
- No reflections on the windshield
- No direct sunlight
Dynamic Calibrations
Dynamic Calibrations require suitable road conditions with clear lane markings,
appropriate highway speeds with limited traffic as required by each individual
OEM. Many of these dynamic calibrations can take up to 3 hours by a certified
technician to complete the drive cycle to ensure the vehicle is in the correct state
to complete the calibration.
Why You Shouldn't Compromise
Roadside or cluttered shops attempting ADAS calibrations can face significant issues, including misaligned sensors, inaccurate calibrations, and potential liability if accidents occur due to malfunctioning safety features. These problems arise due to lack of suitable environments, interference from from sunlight, wind, etc.
Liability
If a vehicle involved in an accident has improperly calibrated ADAS systems, the repair shop could face liability if it's determined that the malfunction contributed to the accident. Customers may also seek accountability if safety features fail to work as intended.
